Instructions for use of color-coated board
Release time：2022-08-26
1. Precautions for the selection of color-coated boards:
The color-coated board is selected according to the end use purpose, which is suitable for use and cost-effective. Mainly consider the external atmospheric environment and the relatively closed internal environment contacted by the color-coated board, that is, the rural atmosphere, urban atmosphere, industrial atmosphere, marine atmosphere, and at the same time consider acid, alkali, salt, humidity, light, ventilation, etc. specific to actual use In the specific environment, the selection of materials can be judged individually.
2. Precautions for storage, transportation and handling of color-coated panels:
1. The color-coated products should be stored in a dry and ventilated environment, and should be kept away from organic solvents and corrosive media such as acids, alkalis, and salts;
2. In the process of transportation and loading and unloading, the color-coated board should be prevented from rain, snow, fog water intrusion, paint film damage, pollution, bumping, extrusion, etc. resulting in surface rust;
3. The product roll should be transported according to the state when it leaves the factory, and the original packaging cannot be disassembled at will.
3. Precautions for the processing and installation of color-coated panels:
1. According to the design requirements, follow the principle of selecting the same manufacturer and the same batch of products for the same project to avoid affecting the appearance due to color differences;
2. If the product is found to be abnormal in appearance and quality after receiving the goods, stop using it and contact the supplier as soon as possible.
3. Avoid low temperature processing (should be above 7°C) for color-coated boards, select suitable mechanical processing color-coated boards, and check the quality indicators such as product surface and adhesion during processing and use. If there are quality problems, the reasons should be found out and take measures. After the measures are taken, it can continue to be processed and used;
4. In the process of processing and installation, the color-coated board should avoid cutting high-temperature metal powder adhesion, sliding and collision between layers of color tile profiles, applying mechanical tools, stepping on hard shoes, etc. to damage the protective coating of the product, and the fixing bolts should be selected. Waterproof and anti-corrosion material sealing; if surface damage occurs during processing and installation, it should be repaired with special repair paint in time to ensure the service life of the color-coated board;
5. After the color tile is installed, the board surface and incision should be kept clean and kept away from corrosive media such as cement, acid, alkali and salt;
6. Long-term direct sunlight and other ultraviolet light irradiation are forbidden during the transportation, storage, processing and installation of the epoxy back paint of the color-coated board;
7. As a color-coated board for roofing, the installation slope is recommended to be no less than 10 degrees. After the color board is installed, the board surface should be kept clean to ensure the service life of the color-coated board;
Fourth, product anti-counterfeiting precautions:
The company's color-coated products have anti-counterfeiting code on the back, and the products are accompanied by a quality certificate. If you have any questions, you can contact our company at any time.
The company's color coating products use high-quality hot-dip (aluminum) zinc substrates processed by hot-rolled domestic first-tier state-owned steel mills, and use world-renowned Akzo Nobel, Shell, and PPG paint manufacturers. The types of coatings include ordinary polyester (PE) , Silicon Modified Polyester (SMP), High Durability Polyester (HDP), Polyvinylidene Fluoride (PVDF), etc.; focus on creating "high-quality, refined" high corrosion-resistant Pro series products, etc., while producing antistatic panels , Self-cleaning board, purification board, printing board, suede board, anilox board and other functional color-coated products, in order to meet the needs of different users, can be customized for customers.
The company's color coating products rely on the company's advanced management and technical research and development, physical inspection as the support, with excellent processing performance, durability and rich and diverse colors, and can provide individualized small color product development and engineering use according to user needs Technical services are widely used in construction, home appliances, home improvement, specific environments and other industries.
